Sistema di ventilazione del pollame di Frp della mucca della fabbrica dell'aspiratore

Informazioni di base
Luogo di origine: La CINA
Marca: XDA
Numero di modello: XDA-F7
Quantità di ordine minimo: insieme 10
Prezzo: 1000 - 10000 USD
Imballaggi particolari: Norma
Tempi di consegna: 15 - 30 giorni
Termini di pagamento: L/C, T/T
Capacità di alimentazione: 10000 insiemi
Informazioni dettagliate
Materiale della lama: Acciaio inossidabile Dimensione: 36"/50"
Motore del ventilatore del pollame: 380V 50Hz Volume di aria (m3/h): 40000
Contatto: whatsapp 008618830728667
Evidenziare:

Sistema di ventilazione del pollame di Frp

,

aspiratore della cabina della pittura

,

Aspiratore a 8 pollici


Descrizione di prodotto

Hot Sell Heavy Duty Exhaust Fan For Industry/poultry/greenhouse



Introduction:
1,Stainless steel fan blade, light weight, high intensity, good toughness GuoYu fan blade is special designed for top grade efficiency which made of Krupp stainless steel by punch forming. Large air volume, no deformation, no broken, no dust, attractive and durable. The thickness of the stainless steel is 1.2mm. Surface finish BA grade. 2,Fan belt pulley and flange are made of high strength aluminum-magnesium alloy by die-casting. Light weight, lower vibration. Blast- sanding treatment for attractive appearance, eliminate internal stress to improve its own rigidity and stability. 3,Belts are Japanese Mitsubishi brand, ensure the long service life, maintenance free. 4,Both China famous motor and Siemens motor are available. Motor voltage and frequence can be customized.
Main Accessories:
1,Centrifugal system: Centrifugal system open the shutter at completely 90 degree to ensure the lowest air resistance and biggest air volume. When close the sealing can efficiently block light and wind into the poultry farm house. Adopt high quality nylon PA66 to ensure the long service life.
2.V-belt: imported Japan Mitsuboshi or Sanlux belt, B type belt make sure use at least 5 years.
3,Motor: both China high quality motor and Siemens motor are available. Approved by CCC certificate. Protection level:IP55, insulation level: F class.
4,Fan blade: Fan blade is made of stainless steel by punching forming, no dust, attractive and durable. Special blade shape design ensure large air volume, no deformation, no broken, keep air volume same all the way. Thickness 1.2mm, surface finish BA grade.
5,Fan bearing: Bearing adopts imported double-row bearing with special waterproof disign, water can’t enter. High strength, lower noise, maintenance free and long service life.



blade
430 stainless steel, 1.2mm thickness

Linking parts
Aluminium alloy
Frame
Galvanized sheet

Spring
304 stainless steel
Shutter
Galvanized sheet

Fastener parts
Stainless steel
Belt
Japanese Mitsubishi brand

Bearing
Imported double-row bearing, waterproof
Motor
Both China famous brand and Siemens Motor are available

Blade support
Hot-dip galvanized
Voltage
Can be changed to different voltage like 220v, Single phase

Delivery time
As usual 5~7 days
Motor protection class
IP55

Payment term
T/T, L/C
Fan belt pulley
High strength aluminum-magenisum alloy

Motor plate
Hexagon fixed nuts. Can suitable different size of motor.
Fan side
With plastic handle






Sistema di ventilazione del pollame di Frp della mucca della fabbrica dell'aspiratore 0Sistema di ventilazione del pollame di Frp della mucca della fabbrica dell'aspiratore 1Sistema di ventilazione del pollame di Frp della mucca della fabbrica dell'aspiratore 2
